Beiträge von de vrije fries

11419 h and 11435 h are disabled

The programs of both transponders started again at 11,427 H 26,660 Fec 3/4

Zitat von satdxer

On 10723.467 V 32114 1/2 i actually found this program with my OB S3 Mini II:
demo-discovery-221b-a02

SID (100) PMT (1011) PCR (1012)

Video H264 Pid (1012) Active

Audio (eng) AAC Pid (1013) Active

From time to time i hear sound (french language), but i can´t get a picture on the tv screen.
Is it 4K or S2X?

Signal strength: 9,3 dB with 125 cm.

On flysat it is listed as Arianespace promo, MPEG-4/HD.
Is it encrypted?

satdxer

Alles anzeigen

Apparently, some new video and audio versions are being tested.

The video is in AVC High Profile 4.2 (normal and allowed is 4.0) and the audio is 2 channels in ADTS muxing mode.

So if your receiver does not support that, you will have no or poor playback.

Video
ID                                       : 1012 (0x3F4)
Menu ID                                  : 100 (0x64)
Format                                   : AVC
Format/Info                              : Advanced Video Codec
Format profile                           : High@L4.2
Format settings                          : CABAC / 4 Ref Frames
Format settings, CABAC                   : Yes
Format settings, Reference frames        : 4 frames
Codec ID                                 : 27
Duration                                 : 1 min 58 s
Bit rate mode                            : Constant
Nominal bit rate                         : 10 000 kb/s
Width                                    : 1 980 pixels
Height                                   : 1 080 pixels
Display aspect ratio                     : 16:9
Frame rate                               : 25.000 FPS
Color space                              : YUV
Chroma subsampling                       : 4:2:0
Bit depth                                : 8 bits
Scan type                                : Progressive
Bits/(Pixel*Frame)                       : 0.187

Audio
ID                                       : 1013 (0x3F5)
Menu ID                                  : 100 (0x64)
Format                                   : AAC LC
Format/Info                              : Advanced Audio Codec Low Complexity
Format version                           : Version 4
Muxing mode                              : ADTS
Codec ID                                 : 15-2
Duration                                 : 2 min 3 s
Bit rate mode                            : Variable
Channel(s)                               : 2 channels
Channel layout                           : L R
Sampling rate                            : 48.0 kHz
Frame rate                               : 46.875 FPS (1024 SPF)
Compression mode                         : Lossy
Delay relative to video                  : -235 ms
Language                                 : English

Source: Old Satterhand

hoi,

Fotelka tests on the Belintersat 1 satellite

11,230 h 3/4 45,000 dvbs-2 / 8PSK.
45 channels Fta except Dorcel tv HD

11,290 h 3/4 45,000 dvbs-2 / 8PSK.
41 channels Fta except Leo TV

The composition of both multiplexes can vary over time.

hoi,

Zwei neue Frequenzen wurden jetzt aktiviert

12560 v 3/4 30000 dvbs-2
12600 v 3/4 30000 dvbs-2

hoi,

31. Januar bis zum 1. Februar:

11477 v 2/3 30000 wird zu 11475 v 3/4 30000

11513 v 2/3 30000 wird zu 11515 v 3/4 30000

11555 v 3/4 30000 wird zu 12520 v 3/4 30000

11635 v 3/4 30000 wird zu 11555 v 3/4 30000

7. Februar bis zum 8. Februar:

11595 v 3/4 30000 wird zu 12560 v 3/4 30000

11675 v 3/4 30000 wird zu 12600 v 3/4 30000

hoi,

new

12685 v 18000 2/3 DVB-S2/8PSK MPEG-2/4

BBC World News Europe HD
BBC World ME HD
BBC World Russia
BBC World News Europe
spare 3.1

11182 v 19500 2/3 DVB-S2/8PSK MPEG-2

Home +1
GOLD +1
Eden +1
W UK +1
Dave Ireland
Good Food Channel +1
Alibi UK +1
Dave ja vu
Yesterday +1
GOLD Ireland
Alibi Ireland
W Ireland

hoi,

neu:

12.108 h 27.500 dvbs:

A PLUS LIVE (M A)
TOP POP (ARABESK)
Service 3 bis 10 mit Testkarte
Service 11 bis 26 mit schwarzem Bild

alles unverschlüsselt

hoi,

jetzt über eutelsat 10 ost:

11005 H 22500 dvbs-2 / 8Psk:

hoi,

new:
11221 h 3/4 27500:

copy from 10719 h 3/4 27500

hoi,

now on the
eutelsat 7 east:
11678 v 3/4 30000 dvbs-2/8Psk:

hoi,

new:
12156 h 3/4 28333 dvbs-2

hoi,

11644 h 3/4 5500 dvbs-2:
58 radio`s fta ESKS WAWA
same as on the amos satellite

Zitat

Original von de vrije fries
hoi,

11045 v 5000 dvbs-2

strong signal with 1,2m dish in the northen of the netherlands

hoi,

11045 v 5000 dvbs-2

strong signal with 1,2m dish in the northen of the netherlands

hoi,

im norden niederlande mit 120 cm schussel und vantage hd8000s

empfang von 4 transponder
12523 v 6000 IMN
12717 V 3000 Sudan Tx
12721 V 2220 Ashorooq DSNG KR
12724 V 2220 TV2
