45°W C-band liner scan (with opposite polarity)
TBS6903X ;
it very strange to see a big difference in Blindscan's results between IQmonitor-pro & Crzayscan !
Posts by flie
-
-
this is what I can see now : not a good signal !
[SATTYPE]
1=0425
2=1.80m C-13K
[DVB]
0=9
1=3530,L,16550,23,3 ;1.4 (-7.87) dB; 20:57 8/9/2021......................DATA GS ;No Locked
2=3564,L,1054,56,2 ;3.2 (-6.15) dB; 20:57 8/9/2021........................TS ;No Locked FEC changed !
3=3566,L,999,34,2 ;6.1 (-1.81) dB; 20:57 8/9/2021........................TS ;No Locked
4=3570,L,999,35,2 ;4 (-1.5) dB; 20:57 8/9/2021........................TS ;No Locked
5=3577,L,1054,34,2 ;9.8 (1.89) dB; 20:57 8/9/2021........................TS "OPM"
6=3584,L,1299,34,2 ;1.6 (-6.31) dB; 20:57 8/9/2021........................TS ;No Locked
7=3590,L,1299,34,2 ;11.1 (3.19) dB; 20:57 8/9/2021........................TS "NTA"
8=3592,L,1299,34,2 ;7.7 (-0.21) dB; 20:57 8/9/2021........................TS "NTA2"
9=3607,L,11680,34,4 ;3.5 (-9.53) dB; 20:57 8/9/2021......................DATA GS
-
flie what about here
Are You check These?
sorry for the late reply , I will check 42.5°E to night
-
BlindScan will only work if the constellation is correct.
To do this, you need to set in the ini file:
S2X_shift = 42 or 43thank you very much
it works for with me
@ 8°W (+7°W & 7.3°W) ....TBS6903X
IQmonitor -pro with Streamreader 1.2.4.109
Crazyscan with Streamreader 1.2.4.111
Unfortunately steel there is some reflection of some transponders in Ku-High fron Ku-low
some thing has to be repaired in TBS6903X driver or in the Streamreader
-
yes it give that is a bad streamreder ! I just forced to work with IQmonitor
when I press "ok" the older streamreder ,the program never start ,because I replace the streamreader
Feed-reports shows "Frequency 0 Khz" transponders with this streamreader 1.2.4.111 (01.09.2021)
-
TBS6903X @ 15°W
-IQmonitor-pro with old streamreader 1.2.4.109 the H.R.Spectra is good for me
-IQmonitor-pro with updated version of streamreader 1.2.4.111 ; Spectrum and Transponders liste can't be saved !!!
at least this time no SNR=0 with this updated version of streamreader 1.2.4.111 like the old version of the same streamreader 1.2.4.111 ! like what femi said here RE: Neue StreamReaderEX-BDA.
I don't know why Feed-reports Doesn't work ok with me ?!
with Crazy scan with this updated version of streamreader 1.2.4.111 the FFT scan is better than befor , and some hase been changed also in his program : SEARCH_RESULT extended with PLS value ,So need recompile applications which use BLScan(), BLScan2().
https://sourceforge.net/p/crazyscan/code/167/
it will be very good if IQmonitor-por and EBSpro works also with the new TBS "montage ships" carsds : TBS5930,TBS6902SE,TBS6904SE
-
yes Satesco
the FFT scan seems to be repaired with this update of Streamreader 1.2.4.11 (01-09-2021)
Blindscan is also a a little faster and best than before
thanks @ crazycat
I Don't know yet if the problem of " reflection of transponders between Ku-low and Ku-high" is repaired or not ?
-
12348,V,22500 32APSK 3/4
-
Thank you very much Strannik for the Nf-noise lesson
just testing TBS5521 @ 8°W (I chose always 8°W ,because I can see all Transponders from 7°W and 7.3°W and 8°W from this position )
still there are some transponders with 0dB SNR in both programs IQmonitor_pro and Crazyscan
But I think that TBS5521 works now better than before
-
1.80m offset VS 1.80m PF with the same LNB Panorama 13K
Test with IQmonitor pro @22°W
Feed-Reports ;
3747,H,47000,3/4,16APSK ----No locked
3824,V,10300,3/4,8PSK ---------No locked
4024,H,2376,3/4,32APSK-------locked!
3985,H,4000,?,QPSK? -------Unknown !
Still hard to me to read SNR from Feed-Reports
-
1.80m offset VS 1.80m PF with the same LNB Panorama 13K
Test with IQmonitor pro @22°W
1-ultra-high spectrum + manual scan ( locked + No-lcked signals)
1.80m offset SNR.avr.H= 7.19dB ,SNR.avr.V=7.02dB
1.80m PF SNR.avr.H= 7.37dB ,SNR.avr.V=6.78dB
-
I cannot understand why you are not reading the program status bar, where you are constantly asked to double-click on the peaks of unlocked transponders?
sometimes I don't want to destroy IQmonitor's_Transpders-liste with Unlocked signals
------------------------------------------------------------
I have to admit that my dishes are not in the perfect condition
but I do this experiment any way
and that's what make me love C-bant ;whatever if your dish is in good condition or in bad condition
you can always see something in c-band
1.80m offset VS 1.80m PF with the same LNB Panorama 13K
Test with IQmonitor pro @22°W
1- ultra-high spectrum (only locked signal)....
1.80m offset SNR.avr.H= 5.11dB ,SNR.avr.V=3.75dB
1.80m PF SNR.avr.H= 4.84dB ,SNR.avr.V=4.34dB
-
Why don't you show the HR spectrum of IQmonitor?
I already show it here :
-
New Data in R. AOL, I think
4110 R 1250my signal
-
02 Locked GS DATA (continuous stream) Transponder here
Circular scan (3.6-3.8GHz & 4.05-4.2GHz)
many thanks to Qwer ,Feci ,and Superdish for their contributions
1=3746,R,2249,34,4 ;4.4 (-8.63) dB; 1:48 12/7/2021
2=3777,L,999,34,4 ;6.4 (-6.63) dB; 1:48 12/7/2021
-
only 03 Transponders with Encrypted channels in liner scan (3.8-4.05GHz) can be locked here from 66°E
opposite polarity
3883,H,30000,34,2 ;8.2 (0.29) dB; 21:57 11/7/2021
3923,H,30000,34,2 ;7.9 (-0.01) dB; 21:57 11/7/2021
3963,H,12330,34,2 ;3.9 (-0.13) dB; 21:57 11/7/2021
-
An other test @ 68.5°E C-band-liner scan opposite polarity- ,one locked transponder in small symbol rate with IQmonitor_pro ;3610,V,257
-
Best DVB-s and DVB-S2 signal here for this position 68.5°E
4081,H,3555,34,1 ;13.1 (7.64) dB; 3:35 11/7/2021 DVB-S
4114,H,8799,56,2 ;10 (0.65) dB; 3:35 11/7/2021 DVB-S2
-
03 locked transponders here .....10° above the Horizon
opposite polarity with my LNB in Liner scan.
GS DATA Continuous stream
3983,V,13500,23,2 ;2.9 (-0.5) dB; 0:08 11/7/2021
4053,H,1665,23,3 ;10.6 (1.33) dB; 0:08 11/7/2021
4058,H,4041,34,4 ;3.3 (-9.73) dB; 0:08 11/7/2021
-
only 02 transponders are locked here ...9°above the Horizon
opposite polarity !
3632,V,5999,35,2 ;5.7 (0.2) dB; 21:17 10/7/2021
4085,H,5599,34,2 ;7.8 (-0.11) dB; 21:17 10/7/2021
